Description
Specifications
• Dimensions:
Thickness: 0.1mm – 6mm
Width: 610mm, 1000mm, 4’(1219mm), 1220mm, 1500mm, 2000mm
*Customized size needs to be confirmed with us
Standards
Manufactured in compliance with the main international specifications and standards including: ASTM, EN, and DIN.
Our copper coil can also be manufactured to meet the requirements of other international standards, including: ASME, SAE, AMS, AWS, FED, MIL, QQ, ISO, BS, AFNOR and JIS.
Features
High corrosion resistance – It translates into impressive service factor.
Unmatched tensile strength which means unbeatable resistance to deformation or failure.
Superior finish – Translates into reduced friction points.
Applications
• Heat Exchanger
• Electrical
• Circuit boards
• Transformers
• EMI/RFI Shielding
• Cable Wrap
• Arts & Crafts
• Batteries
• Electronics
• Appliances
• Solar / Alternative Energy
• Structural Engineering
• Household Products
• Coins
• Medical
• Musical Instruments
• Architecture
• Roofing
• Motors
Main Grades
| Classification | United Kingdom (BS) | Germany (DIN) | Japan (JIS) | EN (symbol) | EN (Number) | China | America (ASTM) |
| Copper | C102 | ECu-58 | C1100 | Cu-ETP | CW004A | T2 | C11000 |
| Oxygen-free Copper | C103 | OF-Cu | C1020 | Cu-OF | CW008A | TU1 | C10200 |
| Phosphorized Copper | C106 | SW-Cu | C1201 | Cu-DLP | CW023A | TP1 | C12000 |
| SF-Cu | C12100 | 121 | |||||
| C106 | 2.0090/2.0076 | C12200 | 122 | ||||
| Silver containing Copper | C101 | CuAg0.1 | C1271 | TAg0.08 | C13000 | ||
| C12900 | 129 | ||||||
| Cadmium Copper | C108 | CuCd1 | CuCd1 | CuCd1 | CW131C | TCd1 | C16200 |
| Berryllium Copper | C112 | CuCo2Be | CuCo2Be | CuCo2Be | CW104C | TBe0.6-2.5 | C17600 |
| Brass | CZ125 | CuZn5 | C2100 | CuZn5 | CW500L | H96 | C21000 |
| CZ101 | CuZn10 | 2.023 | CuZn10 | CW501L | CuZn10 | C22000 | 220 |
| CZ102 | CuZn15 | 2.024 | CuZn15 | CW502L | CuZn15 | C23000 | 230 |
| CZ103 | CuZn20 | 2.025 | CuZn20 | CW503L | CuZn20 | C24000 | 240 |
| CZ106 | CuZn30 | 2.0265 | CuZn30 | CW505L | CuZn30 | C26000 | 260 |
| CZ126 | C26100 | ||||||
| CuZn33 | 2.028 | CuZn33 | CuZn33 | C26200 | 262 | ||
| CZ107 | CuZn36 | 2.0335 | CuZn33 | CW506L | C26800 | 268 | |
| CuZn36 | CuZn36 | C27000 | 270 | ||||
| CZ108 | CuZn37 | 2.0321 | CuZn36 | C27400 | 274 | ||
| CuZn37 | CW508L | C27200 | 272 | ||||
| CuZn40 | 2.036 | CuZn40 | CW617N | C28000 | 280 | ||
| CZ109 | CuZn40 | 2.036 | CuZn40 | CW617N | C28000 | 280 | |
| DCB1 | G-CuZn37Al1 | 2.0595.02 | CuZn37Al1-C | CuZn40Y40 | C85800 | 858 | |
| G-CuZn25Al5 | 2.0598.03 | CuZn25Al5Mn4Fe3-C | CuZn19Al6Y20 | C86200 | 862 | ||
| HTB1 | G-CuZn34Al2 | G-CuZn34Al2 | CuZn32Al2Mn2Fe1-C | CuZn30AlFeMn | C86400 | 864 | |
| CZ118 | CuZn36Pb1.5 | 2.0331 | CuZn35Pb1 | CW625N | CuZn35Pb2 | C34000 | 340 |
| Leaded Brass | CZ119 | CuZn36pb1.5 | C3560 | CuZn36pb1.5 | HPb63-3 | C34500 | |
| CZ124 | CuZn36pb3 | CuZn36pb3 | C34700 | 347 | |||
| CuZn37pb0.5 | 2.0332 | CuZn37pb0.5 | C34900 | 349 | |||
| CZ120 | C36000 | 360 | |||||
| CZ123 | CuZn39Pb0.5 | CuZn39Pb0.5 | CuZn37Pb1 | CuZn39Pb0.8 | C36500 | 365 | |
| CuZn32pb2 | CuZn32pb2 | C35300 | 353 | ||||
| CZ129 | CuZn38Pb1.5 | CuZn38Pb1.5 | CuZn38Pb1 | C37000 | 370 | ||
| Z120 | CuZn39Pb2 | 2.038 | CuZn39Pb2 | CuZn39Pb2 | C37700 | 377 | |
| CZ122 | CuZn39pb3 | 2.038 | CuZn39pb3 | CuZn39pb3 | C37800 | 378 | |
| CZ121 | 2.0401 | C38000 | 380 | ||||
| CZ121/3 | CuZn39Pb3 | 2.0401 | CuZn39Pb3 | CuZn39Pb3 | C38500 | 385 | |
| Tin Brass | CuZn38Sn1 | C4640 | CuZn38Sn1As | C46400 | |||
| Phosphor Bronze | PB101 | CuSn4 | C5102 | CuSn4 | CW451K | QSn5-0.2 | C51100 |
| CT1 | G-CuSn10 | 2.1050.01 | CuSn10-C | CuSn8 | C90700 | 907 | |
| PB2 | G-CuSn12 | 2.1052.04 | CuSn12-C | CuSn12-C | C91700 | 917 | |
| PB1 | CuSn10P | CuSn10P | CuSn11P-C | CuSn10P | |||
| Aluminium Bronze | CuAl5As | CuAl5As | C60800 | ||||
| CA104 | CuAl10Ni5Fe4 | 2.0966 | CuAl10Ni5Fe4 | CuAl9Ni5Fe3 | C63000 | 630 | |
| Silicon Resd Brass | G-CuZn15Si4 | SzBC2 | CuZn16Si4-C | C87500 | |||
| SCB3 | G-CuZn33Pb | 2.0290.01 | CuZn33Pb2-C | CuZn33PbY20 | |||
| Leaded Tin Bronze | LB2 | G-CuPb10Sn | LBC3 | CuSn10Pb10-C | C93700 |
Tolerances
Our copper coil is manufactured in compliance with the main international specifications. Tighter tolerances are available upon request. Custom tempers are available upon request.
Surface Finishes
Oil-free surface
Electro plating
Hot-dip tin plating
Deburred or rounded edges
Bright and polished surfaces
Coil with protective coatings
Profiled coil by either milling or stamping
Packaging
Standard Packaging
Horizontal or vertical axis packaging available
Core types: Fiber, Aluminum, Steel, Plastic
Inner Diameter (ID) as required
Outer Diameter (OD) as required
Inserts as required
Wooden Pallets or Crates
Custom Packaging
Custom packaging, coil weights, inner diameters and outer diameters are available upon request.
